Openvox SWG-M202W 2 2G 3G Channels Wireless 2nd Gen Gateway
Regular price $409.00 Sale price $359.92 Save $49.08
Model: SWG-M202W
Retail Price: $409.00
Please call 626-628-8307 before ordering.
SWG-M202W comes with 2 WCDMA Channels
WCDMA UMTS Band 850/1900Mhz (America)
GSM Band: 850/900/1800/1900MHz (America)
Overview
OpenVox SWG-M20x series wireless gateways include SWG-M202G/W/L and SWG-M204G/W/L. SWG-M20X series wireless gateways support multiple codecs, including G.711U, G.711A, GSM, G.722, G.726, G.729 multiple coding. The gateways support SMS messages sending, receiving, group sending and SMS to E-mail.
The SWG-M20x series gateways are 100% compatible with Asterisk, 3CX, FreePBX, FreeSWITCH SIP server and VOS VoIP operating platform.
VoIP Features
- Support SIP，IAX2 Protocol
- Add, Modify & Delete SIP/IAX2 Trunk
- SIP/IAX2 Registration with Domain
- SIP V2.0 RFC3261 Compliance
- DTMF Mode: RFC2833/Inband/SIP Info
- Multiple SIP/IAX2 Registrations modes
- Abundant Codecs:G.711A, G.711U, G.729, G.722, G.726, GSM
Management Feature
- Simple and convenient configuration via Web GUI
- Support maintenance and configuration by SSH
- Support configuration files backup and upload
- Support Chinese and English page
- Firmware Update by HTTP
- Support Web and SSH login password modification
- Restore Factory Settings
- CDR(More than 200,000 Lines CDRs Storage Locally)
- System log
- SIP/IAX2 log
- TCP and SIP capture
System Features
- Combine Different SIP/IAX2 Trunk into Group
- CLID Display & Hide (Need operators' support )
- Random call interval
- Call Duration Limitation
- Single Call Duration Limitation
- Real Open API Protocol (based on Asterisk)
- Support DISA
- SMSC/SMS/USSD
- PIN Identification
- Optional Voice Codec
- Ports Group Management
- SMS Remotely Controlling Gateway
- SMS Bulk Transceiver, Sent to Email and Automatically Resend
- SMS Coding/Detecting Automatically Identification
- SMS Forwarding and Quick Reply
- USSD transceiver
- Outbound
- Automatically Reboot
- Support MMP
- Support for custom scripts, dialplans
- Support Openvox cloud manage
Operational Specifications
- Module Type: WCDMA
- Channels: 2
- Band: GSM 850/900/1800/1900Mhz; UTMS 850/1900MHz
- Sim Card Handling: Hot-Swap
- LAN: 1x 10/100M
- WAN: 1x 10/100M
- Power: 16W (100-240v Power Adapter included)
Physical Specifications
- Weight: 1.07 Pounds (487 grams)
- Dimensions: 8.11" x 4.92" x 1.06" (206mm x 125mm x 27mm)
Warranty:
- 1 Year Limited Manufacturer Warranty
