OpenVox D1630E 16 Port T1/E1/J1 PRI PCI-E Card Advanced Edition

SKU: D1630E
Regular price $2,639.12 Sale price $2,639.12 Regular price $2,999.00
Sale 12.0% $359.88 (12.0%)
Shipping calculated at checkout.
Out of stock

Model: D1630E
Retail Price:  $2,999.00

D1630E 16 Port T1 E1 PRI PCI-E Advanced Edition Card

This is a SPECIAL ORDER item shipping directly from the factory.
Please call 626-628-8307 before placing your order.

OpenVox D(E)1630E is a 16 T1/E1/J1 ports superior card which supports up to 480 concurrent calls in a single PCI Expression slot. With high performance, OpenVox D(E)1630E is compatible with Linux operating system and most of the commercial servers and motherboards. In addition, The on-board Octasic® DSP-based echo cancellation modules enhances the audio quality greatly as well as reduces CPU usage so as to optimize the system performance.

D(E)1630E supports a wide range of voice protocols including PRI, SS7, R2.

What’s more, D(E)1630E works with Asterisk®, FreeSWITCH®, PBX in a flash, Yate® and IPPBX/IVR projects as well as other open source and proprietary PBX, Switch, IVR, and VoIP

Target Applications

  • Voice-over Internet Protocol (VoIP) Services
  • Complex IVR Trees
  • "Meet-Me" Bridge Conferencing
  • Calling Card Platforms
  • VoIP Gateways (support SIP, H.323, and IAX)
  • Legacy PBX/IVR Services
  • Voice/Data Router (replace expensive routers)
  • PRI/Switch Compatibility - Network or CPE
Telephony Interface
16 E1/T1/J1 Spans

Wiring Connection
  • 68 pin SCSI type interface with RJ45 breakout panel
Hardware and Software Requirements
  • RAM 2GB
  • Kernel 2.4X or 2.6X or 3.0X and above Compatible with Linux
  • CPU 3.3GHZ
E1/T1/J1 Protocols
  • PRI
  • SS7
  • R2
Power Consumption
Power Consumption Voltage: 3.3V, 12V
Power: 5.2W Minimum, 7.8W Maximum at 3.3V or 12V

  • Operation temperature: 0-50℃
  • Storage temperature:-40℃-125℃
  • Humidity: 10-90 non-condensing
Operating Systems
Linux Operating System(all version, releases and distributions in 1.0 up)


  • 1 Year Limited Manufacturer Warranty
