Vendor: Openvox

Openvox IX240 Asterisk N2930 4G RAM 240G HDD 2U Rack PBX Appliance

SKU: IX240
Regular price $1,143.12 Sale price $1,143.12 Regular price $1,299.00
Sale 12.0% $155.88 (12.0%)
Shipping calculated at checkout.
In stock: 2
Description

Model: IX240
Retail Price:  $1,299.00

Overview

OpenVox IX240 is a standard 19” 2U PBX appliance. The IX240 allows users to integrate up to 2 pieces of OpenVox PCI-E telephony interface cards, with any combinations of analog, BRI, PRI or transcoding interfaces. The optional hardware RAID 1 support provides better data backup for your system. The optional HDD case provides the possibility for hot plug function to the storage device. When optional RAID1 is installed and activated, users can see the status of the storage devices from a GUI and allows simple plug and play replacement of with a backup HDD without the need to open nor to power down the appliance.

The IX240 is fitted with the powerful Intel Quad Core Processor. can easily handle 600 concurrent calls and up to 1000 users.

The IX240 supports comprehensive protocol processing, including SIP, H.323 protocols in IP side and BRI, PRI, SS7 and some protocols transcoding in CPE. Taking the full advantages of open source platform, the IX240 will be preloaded with Issabel,Elastix,FreePBX,VitalPBX or BrikerPBX software.

Technical Specifications:

  • UPS: Yes (Optional - not included)
  • RAID: Yes (Optional - not included)
  • CPU: 1.83GHz Intel(R) Celeron(R) N2930
  • RAM: 2 GB DDR3L 1333 (expandable to optional 8GB)
  • Storage:64GB SSD, 1 mSATA Socket (optional)
  • USB: 2 USB 2.0 Ports
  • Ethernet: 2 Gigabit Ports
  • PCIE Interface: 2 PCIe sockets for full length voice cards and other expansion
  • Mini PCIE: Yes
  • Power Supply: 100-240V AC (Built-In)
  • Reduandant Power Supply: Yes (Optional - not included)
  • Display Port: 1 VGA port (DB15)
  • LCD: Yes (Front Display)

Physical Features

  • 19" 2U Rack/Wall Mountable (Ears Included)
  • Dimension: 17.32"x2.63"x14.56" (44cm×6.67cm×370cm)
  • Weight: 16.10 Pounds (7,300g) (Telephony cards not included)

Software & Platform:

  • Issabel-20170714
  • Elastix-2.5
  • Elastix-4.0
  • FreePBX-1712 (default preloaded opensource software)

OpenVox Telephony Cards Options:

  • A400E, A810E, A1610E, A2410E
  • B100E, B200E, B400E
  • D130E, D230E, D430E
  • G410E

*The IX240 supports up to any 2 PCIE cards combination

What is Included

  • IX240 PBX Appliance, 2GB RAM, 64GB SSD, Ear Mount, Power Supply, Power Cord
  • Datasheet & Quick Guide
  • Pre-Installed Open Source Asterisk Issabel

What is NOT Included

  • Open Source Software Support is NOT included and is sold separately.

Warranty:

  • 1 Year Limited Manufacturer Warranty




..jeff..

📃
