Vendor: Openvox

Openvox GW1202-4W Desktop Wireless Gateway 4 2G 3G Channels - Clearance!

SKU: GW1202-4W
Regular price $448.39 Sale price $448.39 Regular price $509.53
Sale 12.0% $61.14 (12.0%)
Shipping calculated at checkout.
In stock: 2
Description

This ITEM is NOT AVAILABLE for the USA.


Model: GW1202-4W
Retail Price: $509.53

Now shipping New Generation Model V2.

The OpenVox GW1202v2, GW1600v2, GW2120v2 Wireless Gateway Series comes with very friendly GUI for software configuration. The hardware is designed with flexibility and expandability in mind. This allows users to easily set the gateway for use with any wireless or analog modules.

The GW1202v2, GW1600v2, GW2120v2 Wireless Gateway series can house from 1 module to 11 modules. The "W" series uses the WCDMA UMTS and GSM Band Frequency, some states, cities no longer offer GSM WCDMA frequency series.  If GSM and WCDMA UMTS band is not available in your location, please select the LTE Band frequency under the "L" series.

The GW1202v2, GW1600v2, GW2120v2 Wireless Gateway series is developed for interconnecting a wide a selection of codecs, including G.711A, G.711U, G.729, G.722, G.723, G.726 & GSM, CDMA to the 4G LTE networks to easily reduce telecommunication expense and maximize cost-savings.

With the unique design of the OpenVox Wireless Gateway, comes easy hot swapping for the SIM cards in any of the installed modules. Users can also add or remove the modules for hardware expansion. Each 4G LTE module runs an independent asterisk system built into. The Wireless gateways comes with a LAN ethernet switch board that provides stickability for hardware upgrade.

The OpenVox Gateways support SMS messages sending and receiving individually or by grouping. This also fully support SMS to email. The Wireless Gateway use standard SIP protocol and compatible with the leading IMS/NGN platform, IPPBX and SIP servers, fully supports the VoIP operating platforms such as Asterisk, Elastix, FreePBX, 3CX BroadSoft and FreeSWITCH.

Technical Specifications:
  • 4 to 44 WCDMA CDMA UTMS Channels
  • GW1202v2 Series, 4 to 8 Channels
  • GW1600v2 Series, 4 to 20 Channels
  • GW2120v2 Series, 4 to 44 Channels
  • 1 SIM card per GSM Channel
  • Frequency Range:
    • GSM 850/900/1800/1900MHz
    • UMTS 850/1900MHz
  • 10/100M LAN interfaces
  • Up to 8 Standard SMA-K interfaces
  • Storage temperature range: -20~70℃
  • Operation temperature range: 0~40℃
  • Operation humidity range: 10%~90% non-condensing
  • Power source: 12V DC/2A 120-240V
  • Dimension:
    • GW1202v2: 6" x 7.5" x 1.7"
    • GW1600v2: 17.3" x 11.8" x 1.8"
    • GW2120v2: 19.1" x 13.1" x 3.5"
  • Weight (without the modules)
    • GW1202v2: 4 Pounds
    • GW1600v2: 12 Pounds
    • GW2120v2: 18 Pounds
Features
  • Simple and convenient configuration via Web GUI
  • Support http / https / SSH
  • Basic security strategy (white/blacklist, security rules)
  • Optional GSM Voice Codec
  • Codecs support:
  • G.711A
  • G.711U
  • G.729
  • G.723.1
  • G.722
  • G.726
  • GSM
  • SIP (RFC3261) Compliance
  • Support diverse SIP, IAX2 protocols.
  • Multiple SIP/IAX2 Registration models: None, server, client
  • DTMF Signaling support: RFC2833, Inband, SIPINFO
  • Real Open API Protocol (based on Asterisk)
  • Support static IP and DHCP
  • Call Duration Limit
  • CLIR (Call Line Identification Restriction)
  • Call Waiting
  • Call Forwarding (unconditional, no reply, busy, not reachable)
  • SMSC/SMS/USSD
  • SMS bulk transceiver, SMS automatically resend, Sent to Email
  • Support HTTP SMS interface
  • SMS Forwarding
  • USSD transceiver
  • SMS remotely controlling gateway.
  • IMEI number automatic modification
  • PIN identification
  • Mobile number portability (MNP)
  • Flexible routing settings & unlimited routing rules
  • Support DISA
  • Extensible Automatic Callback and Speed Dial
  • Customizable IVR
  • CDR (More than 200,000 Lines CDRs Storage Locally)
  • Support configuration files backup and upload
  • Support for custom scripts, dial plans
  • Least Cost Routing (LCR), according to Time, Port, Calling Number
  • Independent System for Each Module
  • Affordable Price with Superior Performance
  • Hot-swap Design for both Sim cards and Modules
  • Compatible with sip server, such as: Asterisk, Elastix, 3CX, FreeSWITCH
Software & Platform:
  • Asterisk / Linux
Certifications
  • Certificates: CE

    Warranty:

    • One Year Limited Manufacturer Warranty

    GW GW WCDMA UMTS GSM Series Model Configuration Guide

    Model Description
    GW1202v2 Chassis Only - No Modules
    GW1202v2-4W 4 WCDMA Channels (1 GWM4x0W Module)
    GW1202v2-8W 8 WCDMA Channels (2 GWM4x0W Modules)
    GW1600v2
    Chassis Only - No Modules
    GW1600v2-4W 4 WCDMA Channels (1 GWM4x0W Module1)
    GW1600v2-8W 8 WCDMA Channels (2 GWM4x0W Modules)
    GW1600v2-12W 12 WCDMA Channels (3 GWM4x0W Modules)
    GW1600v2-16W 16 WCDMA Channels (4 GWM4x0W Modules)
    GW1600v2-20W 20 WCDMA Channels (5 GWM4x0W Modules)
    GW2120v2 Chassis Only - No Modules
    GW2120v2-4W 4 WCDMA Channels (1 GWM4x0W Module1)
    GW2120v2-8W 8 WCDMA Channels (2 GWM4x0W Modules)
    GW2120v2-12W 12 WCDMA Channels (3 GWM4x0W Modules)
    GW2120v2-16W 16 WCDMA Channels (4 GWM4x0W Modules)
    GW2120v2-20W 20 WCDMA Channels (5 GWM4x0W Modules)
    GW2120v2-24W 24 WCDMA Channels (6 GWM4x0W Modules)
    GW2120v2-28W 28 WCDMA Channels (7 GWM4x0W Modules)
    GW2120v2-32W 32 WCDMA Channels (8 GWM4x0W Modules)
    GW2120v2-36W 36 WCDMA Channels (9 GWM4x0W Modules)
    GW2120v2-40W 40 WCDMA Channels (10 GWM4x0W Modules)
    GW2120v2-44W
    44 WCDMA Channels (11 GWM4x0W Modules)
