OpenVox IX132 Asterisk D2550 2G RAM 500G HDD 1U Rack PBX Appliance
SKU: IX132
$747.12 $747.12 $849.00
Sale 12.0% $101.88 (12.0%)
Shipping calculated at checkout.
In stock: 3
Description

Model: IX132
Retail Price:  $849.00

The IX132 comes without FXO FXS Modules, they are sold separately as options. Please call 626-628-8307 for any questions.

Product Spotlight
The IX132 is a 1U Rackmount Appliance with a Full Feature Open-Source Asterisk IPPBX preinstalled.
  • Modular Design for Telephony Cards Connection
  • Intel Atom Dual core D2550(1.86GHz)
  • Optional Hardware RAID 1 Support
  • Optional Pre-Loaded Open Source IPPBX System
  • Combination of analog, BRI, PRI, or transcoding interfaces
Overview
OpenVox IX132 is a standard 19” 1U appliance. It allows users to integrate up to 2 pieces of OpenVox PCI-E telephony interface cards, with any combinations of analog, BRI, PRI, or transcoding interfaces. The optional hardware RAID 1 support provides better data backup for your system. The optional HDD case provides the possibility for hot plug function to the storage device. When RAID1 is installed, users can see the status of the storage devices from a GUI and then simply replace a backup HDD whenever needed without opening the appliance. What’s more, the IX132 provides two flexible ways of power supply: internal and external and it’s up to you to select one of them to power up the IX132.

The IX132 supports comprehensive protocol processing, including SIP, H.323 protocols in IP side and BRI, PRI, SS7, and some protocols transcoding in CPE. Taking the full advantages of open source platform, the IX132 will be preloaded with Elastix®, PBX in a FlashTM, FreePBX or trixbox® IPPBX software.

Technical Specifications:
  • CPU: 1.86GHz Intel Atom Dual core D2550
  • 1 M L2 cache, 64 bit instruction
  • DRAM: 2 GB DDR3 SDRAM,
  • Storage: 1 SATA slot, 1 mSATA Socket
  • 2 USB 2.0 Ports
  • 2 Ethernet Ports (1000Mbps speed)
  • 2 PCIe sockets for voice cards and other expansion
  • 1 mini PCI-E socket for extension
  • 16 Mbit flash for AMI BIOS
  • Voltage range :12V DC supply through DC jack
  • 1 VGA port (DB15) for display interface
  • Header for LPC bus (use for flash recovery or I/O expansion)
  • Low EMI Emission level and high Electro Magnetic Susceptibility
  • Rack/Wall Mountable
  • Firmware: AMI_UEFI BIOS
  • Dimension: 44cm × 4.5cm × 30cm
  • Weight: 5200g （telephony cards not included and are sold separately）
Features:
  • Attend Transfer
  • Blind Transfer
  • BLF Support
  • Blacklist
  • Callback
  • CDR (Call Detail Records)
  • Call Forward
  • Call Parking
  • Call Pickup
  • Call Routing
  • Call Transfer
  • Call Waiting
  • Caller ID
  • Conference
  • Define Office Time
  • DDNS
  • Dial by Name
  • DISA (Direct Inward System Access)
  • DIDs
  • Distinctive Ringtone
  • DND (Do Not Disturb)
  • FAX (T.38)
  • Firewall
  • Follow Me
  • IVR (Interactive Voice Response)
  • Intercom/Zone Intercom
  • Mobility Extension
  • Multi-language Prompt
  • Music On Hold
  • Music On Transfer
  • One touch record
  • OpenVPN
  • Phone Provisioning
  • PIN User(PIN Code Control)
  • Paging/Zone Paging
  • PPPoE
  • Queue
  • Ring Group
  • Route by Caller ID
  • Skype Integration (Sky2Sip)
  • SMS to Mail/Mail to SMS
  • Speed Dial
  • Static Route
  • Three Way Calling
  • Voicemail
  • Voicemail to Email
  • Voicemail Forwarding
  • Web Based Control Panel
  • Software & Platform: Elastix®, trixbox®, PBX in a FlashTM, FreePBX
OpenVox Telephony Cards Options:
  • A400E/810E/1610E
  • B100E/200E/400E
  • D130E/230E/430E
  • A1610E can be installed in IX132 .

Warranty:

  • 1 Year Limited Manufacturer Warranty
