OpenVox SWG-3032L 2G 3G 4G LTE 32 Channels Wireless Gateway

Model: SWG-3032L-AF
Retail Price:  $4,249.00

Specifications
OpenVox SWG-3032 series wireless gateways which can compatible with a series of modules(2G/3G/4G), enabling interconncetion between GSM / WCDMA / LTE network and VoIP network safely and efficiently. It can bring you excellent HD voice service with multiple codecs, including G.711U, G.711A, GSM, G.722, G.726, G.729 . Our products support SMS messages sending, receiving, group sending and SMS to E-mail. The SWG-3032 series gateways is perfect compatible with Asterisk, 3CX, FreePBX, FreeSWITCH SIP server and VOS VoIP system platform. It can provides users with more diverse telecommunications access methods and helps users reduce communication costs.

Product Name: SWG-3032L
Module Type: WCDMA / LTE
Module Number: 32
Channel Number: 32
Band:
China/India
LTE FDD: B1/B3/B5/B8
LTE TDD: B38/B39/B40/B41
WCDMA: B1/B8
TD-SCDMA: B34/B39
CDMA: BC0
GSM: 900/1800MHz

Europe/Middle East/Africa/Korea/Thailand
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B88

North America
LTE FDD: B2/B4/B5/
B12/B13/B14/B66/B71
WCDMA: B2/B4/B5

Australia/New Zealand/Taiwan/Brazil
LTE FDD: B1/B2/B3/B4/B5/
B7/B8/B28
LTE TDD: B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8

SIM Card: Hot-Swap
LAN: 1*10/100M
WAN: 1*10/100M
USB Micro-B: 1(Supports USB Micro-B storage)
Console: 1
Operaton Temperature: 0℃ ~ 45℃
Operaton Humidity Range: 10% ~ 90%
Storage Temperature Range: -20℃ ~ 70℃

Features
VoIP Characters

• Support SIP，IAX2 Protocol
• Add, Modify & Delete SIP/IAX2 Trunk
• SIP/IAX2 Registration with Domain
• SIP V2.0 RFC3261 Compliance
• DTMF Mode: RFC2833/Inband/SIP Info
• Multiple SIP/IAX2 Registrations modes
• Abundant Codecs:G.711A, G.711U, G.729, G.722, G.726, GSM

Network

• IPv4，UDP/TCP，DHCP，TELNET，HTTP/HTTPS，TFTP
• VPN Type：OpenVPN / PPTP VPN / N2N VPN / L2TP VPN(Not available for EAEU)
• HTTP/SSH（Optcal Telnet）
• Ping & Traceroute Command on the Web
• Simple Security Strategy: white list, black list, security rules

Management

• Simple and convenient configuration via Web GUI
• Support maintenance and configuration by SSH
• Support configuration files backup and upload
• Support Chinese and English page
• Firmware Update by HTTP
• Support Web and SSH login password modification
• Restore Factory Settings
• CDR(More than 200,000 Lines CDRs Storage Locally)
• System log
• SIP/IAX2 log
• TCP and SIP capture

System Features

• Combine Different SIP/IAX2 Trunk into Group
• CLID Display & Hide (Need operators' support )
• Random call interval
• Call Duration Limitation
• Single Call Duration Limitation
• Real Open API Protocol (based on Asterisk)
• Support DISA
• SMSC/SMS/USSD
• PIN Identification
• Optional Voice Codec
• Ports Group Management
• SMS Bulk Transceiver, Sent to Email and Automatically Resend
• SMS Coding/Detecting Automatically Identification
• SMS Remotely Controlling Gateway
• SMS Forwarding and Quick Reply
• Support  SMPP
• USSD transceiver
• Outbound
• Automatically Reboot
• Support MMP / SNMP
• Support for custom scripts, dialplans
• Support Openvox cloud manage


Certification
CE
