Vendor: Openvox

OpenVox MC100-A31EG2 MiniUCS 2Core Atom 2GB 16GB Asterisk VoIP PBX 3 FXS 1 FXO

SKU: MC100-A31EG2
Regular price $659.12 Sale price $659.12 Regular price $749.00
Sale 12.0% $89.88 (12.0%)
Shipping calculated at checkout.
In stock: 1
Description

Model: MC100-A31EG2
Retail Price:  $749.00

Description

MC100 Series equipped with dual core 1.6GHz Intel processor which can support up to 300 extensions and 240 concurrent calls. With two Gigabit Ethernet ports and two USB interfaces in the back panel make the compact and portable MC100 Series more popularity among the market. Using only up to 14W of power and a flash hard drive, MC100 Series are sustainable with low energy consumption and no moving parts. Analog or BRI digital connectivity will be available for MC100 Series, you can choose one of the following configuration to meet your needs. Analog or BRI digital configuration for MC100 are as follow:

OpenVox MC100 Series PBX Model Configuration
  FXS FXO BRI T1/E1
MC100-000 0 0 0 0
MC100-A40EG2 4 0 0 0
MC100-A04EG2 0 4 0 0
MC100-A22EG2 2 2 0 0
MC100-A31EG2 3 1 0 0
MC100-A44EG2 4 4 0 0
MC100-A80EG2 8 0 0 0
MC100-A08EG2 0 8 0 0
MC100-B2EG2 0 0 2 0
MC100-B4EG2 0 0 4 0
MC100-D1EG2 0 0 0 1
MC100-DE1EG2 0 0 0 1 w EC

Technical Specification

  • FXO Port: up to 8 (See Model Configuration Table)
  • FXS Port: up to 8 (See Model Configuration Table)
  • BRI Port: up to 4 (See Model Configuration Table)
  • T1/E1/J1 Port: 1 (See Model Configuration Table)
  • PCI Expression Slot: 1
  • Operating System: Elastix 4.0
  • UCP: 1.6GHz
  • Extensions: Up to 300
  • Concurrent Calls: Up to 240
  • RAM: 2GB
  • Storage: 2 Gigabit Ethernet
  • Storage: 16GB SSD
  • Network Ports: 2 Gigabit Ethernet
  • USB Ports: 2
  • Power Consumption: 14W
  • Operating Voltage: 100/240VAC
  • Dimension: 181mm×158mm×56mm
  • Weight: 1235g

    Features:

    • Hardware Detection Interface
    • Integrated Echo Cancellation
    • Distributed dialplan with Dundi
    • Configurable and Flexible IVR
    • Voice Mail
    • Fax-to-Email
    • Support for Soft Phones
    • Web Interface Configuration
    • Virtual Conference Rooms
    • Call recording
    • Least Cost Routing
    • Extension Roaming
    • PBX Interconnection
    • Caller ID
    • CRM
    • Advance Reports
    • Advanced Dialing Rules
    • Blacklist
    • Call Detail Records (CDR)
    • Call Waiting
    • Fax Support
    • SIP/IAX trunk & PSTN Connectivity
    • Firewall
    • Follow me
    • Music on Hold
    • Music on Transfer
    • Ring Group Call Queues
    • Three-way Calling

    Warranty:

    • 1 Year Limited Manufacturer Warranty




    ..jeff..

    📃
